Material:Stainless Steel
Temperature Range:-180°C to +180°C
Process Size:22mm to 64mm
Thread Type:NPT, BSW
Thread Size:1/2 inch, 3/4 inch
End Connections:Flanged, Socket Weld
Process Connection Code:Y00, S04, S05, S06, F07, F08, T01, T02, T03, T04, T0541
Length:Customizable from 100mm to 1000mm
Pressure Rating:Up to 100 bar
Accuracy:±0.1% of reading ±1 degree Celsius
The Thermo-Kinetics Thermowell WF22-64-TIT-180-1F-99 is meticulously engineered to withstand extreme conditions, ensuring reliable operation in industries requiring precise temperature monitoring.
Crafted from high-grade Stainless Steel 316L, it offers exceptional corrosion resistance and long service life.
With a broad temperature range from -180°C to 180°C, this thermowell is suitable for a wide array of industrial applications, including cryogenic processes and high-temperature operations.
Equipped with a robust pressure rating up to 10 bar, it ensures safety and reliability in high-pressure environments.
The ISO 2853-1 process connection facilitates seamless integration with various industrial equipment, enhancing operational efficiency.
Featuring a 64 mm diameter and 22 mm length, the thermowell is designed to fit standard installation configurations without compromising on performance.
The combination of a M16 x 1.5 thread size, straight end type, and PTFE sealing ensures a secure and leak-proof connection.
Alumina ceramic insulation and epoxy powder coating provide excellent thermal insulation and enhanced protection against external impacts.
Available with a flange mounting option, it can be easily adapted to different installation scenarios, making it versatile for various applications.
