Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary
Frequency Range:0.1 μHz to 20 MHz
Amplitude:±10 Vpp into 50 Ω
Resolution:14-bit vertical resolution
Output Impedance:50 Ω
Phase Shift:±90°
Sampling Rate:up to 100 MSa/s
Memory Depth:16 kPoints
Trigger Source:Internal, External, Manual, Bus
Display:5.6-inch color TFT LCD
Connectivity:USB, LAN, GPIB
The Tektronix 5B42 Arbitrary Function Generator provides a robust solution for generating precise waveforms for various test scenarios. With its advanced digital signal processing capabilities, this device ensures accurate and reliable performance across a broad frequency range. The user-friendly interface includes a 5-inch TFT color LCD display, allowing for easy parameter adjustments and real-time monitoring. Key features include programmable function keys, user-settable default values, and multi-language support, making it versatile for global use. The compact design of just 65 mm depth ensures it can fit seamlessly into any laboratory setup. The generator supports multiple communication interfaces, including USB, Ethernet, GPIB, and RS-232, facilitating integration with existing systems and networks. Whether for research and development or quality assurance, the Tektronix 5B42 is an essential tool for modern engineering laboratories.
