Frequency Range:9 kHz to 50 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Noise, Arbitrary
Output Amplitude:+/- 10 Vpp into 50 Ohms
Output Impedance:50 Ohms
Resolution:14-bit DAC
Bandwidth:50 MHz (-3 dB)
The Tektronix 5A48 Function Generator is designed to meet the needs of engineers and technicians in diverse industrial environments. It provides highly accurate signal generation across a wide range of frequencies and waveforms.
With a user-friendly interface and intuitive navigation, this function generator simplifies the process of creating and modifying signals. Its robust performance ensures reliable operation in demanding test and measurement scenarios.
Equipped with advanced modulation capabilities, including AM, FM, PM, and FSK, the Tektronix 5A48 allows users to simulate complex real-world signals for thorough testing and validation.
This function generator boasts a built-in arbitrary waveform memory that can store up to 16kpts, enabling the creation of customized waveforms for specific application requirements. The memory capacity ensures flexibility and versatility in signal generation tasks.
Designed with connectivity in mind, the Tektronix 5A48 supports multiple interfaces including USB, LAN, GPIB, and RS-232. This facilitates easy integration with other test equipment and systems, streamlining workflow and enhancing productivity.
