Schneider TSX08ED12RD Expansion Module

Type:Expansion Module

Model:TSX08ED12RD

Manufacturer:Schneider Electric

Operating Voltage:24V DC

Input Channels:8 Analog Input

Output Channels:12 Digital Relay Output

Communication Interface:Modbus RTU

Operating Temperature:-20°C to +70°C

Humidity Range:5% to 95% RH (non-condensing)

    The Schneider TSX08ED12RD Expansion Module is engineered to seamlessly integrate with Schneider’s range of programmable logic controllers (PLCs), offering a robust solution for expanding your control system capabilities. Its modular design allows for flexible configuration, making it suitable for a wide array of industrial applications from manufacturing lines to process control systems.

    Key features include a high-speed communication interface, enabling fast data exchange with other components in the network. The module supports Modbus TCP/IP, facilitating compatibility with a broad spectrum of devices and software solutions.

    With 8 inputs and 12 outputs, this expansion module provides ample connectivity options for your automation needs. Each input can handle a wide range of signal types, ensuring versatility in signal acquisition. The outputs are equipped with 8 Form C (SPST) relays, providing reliable switching capabilities for controlling actuators and other load handling tasks.

    Designed for operation within a temperature range of -20°C to +60°C, the Schneider TSX08ED12RD Expansion Module ensures reliable performance in various industrial environments. Its compact size (84 mm x 22 mm x 84 mm) and IP20 protection class make it suitable for mounting on control panels or in confined spaces without compromising on safety.

    The power consumption of 1.5 W (max.) indicates an energy-efficient design, contributing to lower operational costs and reduced environmental impact. This module is an ideal choice for enhancing the functionality of your existing industrial control systems while maintaining a high level of reliability and ease of integration.
