Operating Range:0-100 bar
Accuracy:+/- 1% FS
Repeatability:0.1% FS
Response Time:≤ 0.5 s
Switch Points:Adjustable between 0.5% to 99.5% FS
Environmental Temperature:-25°C to +70°C
Power Consumption:≤ 3 W
Relay Contacts:1 Form A, 1 Form B
Operating Voltage:12 VDC to 30 VDC
Operating Current:≤ 50 mA
Reliability Rating:MTBF > 50,000 hours
Material:Stainless Steel 316L
IP Rating:IP65
Mounting:Panel Mount, IP65 Rated
Dimensions:25 x 125 mm
Weight:Approx. 50 g
The HYDAC EDS1791-N-016-000 is engineered for precision performance, offering unmatched accuracy and reliability in industrial pressure control scenarios. This electronic pressure switch boasts an adjustable operating range from 0 to 690 bar, ensuring it caters to a wide array of applications.
Featuring ±1% of full-scale accuracy and repeatability within ≤ 0.2% of full-scale, the EDS1791-N-016-000 ensures consistent and dependable operation. Its adjustable switching points across the entire operating range provide flexibility in application settings.
Equipped with a robust 1NO + 1NC relay output rated up to 24 VDC, this switch offers a direct and reliable interface for integration into various control systems. It is designed for seamless operation within temperatures ranging from -25°C to +85°C, making it suitable for demanding environments.
The IP65/IP67 protection class of the HYDAC EDS1791-N-016-000 ensures durability against dust and water ingress, enhancing its reliability in outdoor or harsh indoor industrial settings. The power supply compatibility from 12 to 36 VDC ensures easy integration into existing electrical systems.
With its compact design and versatile functionality, the HYDAC EDS1791-N-016-000 Electronic Pressure Switch is the ideal choice for enhancing safety and efficiency in industrial processes, providing operators with precise pressure monitoring and control capabilities.
