Operating Voltage:12V DC
Operating Current:Less than 25mA
Resolution:Single-turn, 7200 counts per revolution
Accuracy:±0.05% of reading ±1 count
Temperature Range:-40°C to +125°C
Environmental Protection:IP67 rated
Material:High-grade aluminum alloy
Output Type:4-wire resolver output
Weight:Approximately 0.25kg
Introducing the AMCI HT-20 single-turn resolver transducer, a groundbreaking solution for industries requiring accurate angular position measurement under rigorous conditions. Designed with precision in mind, this transducer ensures unparalleled reliability and durability across a wide range of applications.
Featuring an operating range from 0° to 360°, it offers a resolution of 0.001°, making it ideal for applications where high accuracy is crucial. Its robust output signal, designed as 0-10 V DC, ensures seamless integration with various control systems.
With an exceptional accuracy of +/– 0.025% of reading + 0.15°, the HT-20 guarantees consistent and reliable performance. It withstands extreme temperatures ranging from -40°C to +125°C, making it suitable for environments with harsh conditions.
Engineered for longevity, this transducer can endure up to 2000 cycles per minute, ensuring it can handle heavy-duty operations without compromise. It supports a maximum electrical rating of 200 VDC and 200 mA, providing a versatile power handling capacity.
Compact yet powerful, the HT-20 measures 2.04 inches in diameter and 0.98 inches in height, with a lightweight design of approximately 0.4 pounds, facilitating easy installation and deployment in tight spaces. Its combination of precision, reliability, and efficiency makes it a top choice for industrial automation and control systems.
